TRACK EXCAVATOR HX8330 ,33TONS TRACK EXCAVATOR

Name: TRACK EXCAVATOR HX8330 ,33TONS TRACK EXCAVATOR
Brand: GUANGZHOU CHUANGSEN MACHINERY TECHNOLOGY CO.,LTD
SKU: HX8330
Price: 92000 USD
Availability: InStock

Brand Name:	HXMG
Model Number:	HX8330
MOQ:	1 unit
Price:	92000 USD
Payment Terms:	T/T, Western Union
Supply Ability:	100 UNITS PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO CE

Swing Speed:

0-11 Rmp

Gradeablity:

35°

Max Bucket Digging Force:

244 KN

Max Arm Digging Force:

200 KN

Power / Revolution Speed:

194/2200KW/rpm

Operation Weight:

33000 Kg

System Pressure:

35 Mpa

Bucket Capacity:

1.6 Cbm

Packaging Details:

IN NUDE

Highlight:

33-ton track excavator machine

heavy-duty track excavator

HX8330 track excavator with warranty

Product Description

ENGINE发动机
Emission Standard排放标准	Tier 2/ Stage II
Make /Model 制造商/型号	Cummins /6CTA8.3
Power /Rotation speed额定功率	194kw@2200rpm
Type 形式	Diesel with water-cooled, 6-cylinder
TRACK SYSTEM履带系统
Maximum Travel speed行驶速度	2.2/4.4 km/h
Width of track shoe履带板宽	600mm
Number of bottom roller per side支重轮数量/每侧	8
PERFORMANCE PARAMETER性能参数
Standard Bucket capacity标准铲斗容量	1.4-1.6m³
Swing speed回转速度	12rpm
Maximum Grade ability最大爬坡度	35°(70%)
Maximum Bucket digging force铲斗最大挖掘力	244KN
Maximum Arm digging force斗杆最大挖掘力	200KN
Hydraulic system pressure系统压力	35Mpa
Machine weight整机重量	33000kg
Fuel tank燃油箱容积
Hydraulic oil tank液压油箱容积
MACHINE SIZE尺寸
Overall dimension (LWH)整机尺寸	11015mm3200mm3168mm
Height of cabin驾驶室高度	3168mm
Track length on ground(Axle base)履带接地长度	3800mm
Track gauge轨距	2590mm
Minimum Ground clearance最小离地间隙	470mm
Swing radius at tail尾部回转半径	3480mm
WORKING RANGE工作范围
Maximum Digging height最大挖掘高度	10491mm
Maximum Dumping height最大卸载高度	7625mm
Maximum Digging depth最大挖掘深度	6437mm
Maximum Vertical digging depth最大垂直挖掘深度	5831mm
Maximum Digging radius最大挖掘半径	10709mm
Minimum swing radius最小回转半径	3643mm

FEATURES AT A GLANCE

Features:

1. Powerful engine for efficient operation. 2. Fuel-efficient for cost savings. 3. Imported hydraulic system for peak performance. 4. Professional-grade structural components for durability. 5. Advanced breaking pipeline for faster work. 6. Humanized design for operator comfort.

Benefits:

1. Maximum performance and reliability. 2. Cost-effective operations. 3. Long-lasting durability. 4. Easy maintenance access. 5. Operator satisfaction and productivity.

Our advantage:

- International famous brand engine - Strong power to meet the requirement of efficient operation. Advanced energy-saving control makes the machine consume less fuel.

- Advanced hydraulic system - pump, valve, swing motor, traveling motor, oil cylinder, pilot operated valve and other components are all of international famous brand, which ensures the quality of the product.

- A variety of attachments can be installed - one machine can be used for multiple purposes, adapting to a variety of working conditions.

- All-round expansion of the field of vision, enlarging the front window, side window and rear window to ensure a wide field of vision, greatly reducing the blind spot, safer and more efficient operation.

- Function switches are centrally arranged on the control panel, easy to select by touching the buttons.

1.Versatile with various attachments options available. Suitable for a wide range of projects. and Promotes productivity on job sites.
2. With an operating weight of approximately 33 tons, the machine ensures excellent stability and strength. Its high-powered engine delivers robust performance for demanding tasks.
3. Crawler Tracks offers excellent traction and maneuverability.
4. Boom and Arm provides significant reach and digging depth.
5. Hydraulic System enables smooth and precise control.
6. Operator Cabin supply comfortable with user-friendly controls.

PRODUCT CONFIGURATION

HX8330 33 TON CRAWLER EXCAVATOR:

1. 1-year/2000-hour warranty for vehicle structural parts. 2. Reliable performance with top-brand hydraulic components. 3. Smooth walking and parking with reducer, and secure hill climbing with brake valve. 4. Enlarged radiator for efficient heat dissipation and low-temperature operation. 5. Low fuel consumption with strong power output. 6. Versatile attachments, including hydraulic tools and buckets, to meet diverse customer needs.

Left-side

Middle

Right-side

Key attributes

Bucket capacity

1.6m³

Moving Type

Crawler Excavator

Engine Brand

Cummins

Hydraulic Pump Brand

Zhongchuan

Hydraulic Cylinder Brand

Eaton

Hydraulic Valve Brand

Zhongchuan

UNIQUE SELLING POINT

High operating efficiency

Warranty

1 Year

Make

HXMG

Machinery Test Report

Provided

Video outgoing-inspection

Provided

Color

Yellow, orange

Core Components

Engine, Pressure Vessel, Pump, Bearing, Gear, Motor, Gearbox

Brand Name

HXMG

Machine Weight

33000 kg

Max Digging Radius

10709mm

Maximum Digging Depth

6437mm

Maximum Digging Height

10491mm

Place of Origin

Shandong, China

Power(W)

194kw

Rated Speed

2.2-4.4km/h

Keywords

33 Ton Heavy Crawler Excavator

Excavator

33 Ton Hydraulic Digger

Engine

Cummins

Application

Construction Mining

MOQ

1 set

Overall dimensions(mm)

11015mm*3200mm*3168mm

Bucket Max Digging force (KN)

244

Arm Max Digging Force(KN)

200

Rated power

194kw

Swing speed(Rmp)

0-11
